SAMSUNG DISPLAY PROFISSIONAL LFD 75"QH75B 4K-700cd 24/7

Diagonal Size75"

TypeVA
Resolution3840x2160(16:9)

Pixel Pitch(mm)0.42975 x 0.42975
Active Display Area(mm)1650.24 (H) x 928.26 (V)
Brightness(Typ.)700 nit

Contrast Ratio6000:1
Viewing Angle(H/V)N/A

Color Gamut92% (DCI-P3, CIE 1976)
Operation Hour24/7

Haze
Non-Glare


Sound

Speaker Type10W 2ch

Connectivity

Input

VideoDP 1.2 (1), HDMI 2.0 (3)

HDCPHDCP2.2
USBUSB 2.0 x 2

Output

AudioStereo mini Jack



External ControlRS232C(in/out), RJ45

BT/WiFiYes

Power

Power SupplyAC 100 - 240 V, 50/60 Hz

Power Consumption

Max[W/h]264.0

Typical[W/h]195.0

Sleep modeless than 0.5W

Mechanical Specification

Dimension (mm)

Set1681.1 x 960.1 x 49.7
Package1871 x 1127 x 223

Weight (kg)

Set40.3
Package51.0



VESA Mount (mm)400 X 400
Bezel Width (mm)11.5mm(U/L/R), 12.5mm(B)

Operation

Operating Temperature0  ℃  ~   40   ℃

Humidity10.0  %  ~   80.0   %

Feature

Key FeaturesUHD Signage with Built-in MagicInfo S10, SSSP 10.0

OrientationLandscape / Portrait

Remote ControlN/A
Special FeaturesH/W : Symmetric Design (same with QxR) Center IR Temperature Sensor Auto Level Wi-Fi(2.4/5.0GHz dual) & BT S/W : Workspace (Microsoft365/VMWare/RDP) Custom Home Auto Source Switching & Recovery Dicom Simulation Mode Director Mode SmartView+(PC) [end of march~] Upgradable Web-Engine Tizen Enterprise Platform Smart Calibration SmartView+(mobile) Video Conference Solution

Internal Player

ProcessorCortex A72 1.7GHz Quad-Core CPU

On-Chip Cache MemoryN/A

Clock SpeedN/A

Main Memory InterfaceN/A
GraphicsN/A

Storage (FDM)16 GB

MultimediaN/A

IO PortsN/A
Operating SystemTizen 6.5

Certification

Safety60950-1 / 62368-1

EMCClass B

Security802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
